Digital Audio PCB Bluetooth Module One Stop Service Multi Color Solder Mask
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Application: | Electronics Device | Service: | One-stop Service |
|---|---|---|---|
| Solder Mask Color: | Blue.green.red.black.white.etc | Testing Service: | 100% |
| Min Lead Pitch: | 0.3mm | Max PCB Size: | 510x460mm |
| High Light: | One Stop Audio Pcb Bluetooth Module,One Stop Service Pcb Bluetooth Module,One Stop bluetooth audio receiver pcb |
||
Digital Bluetooth Audio Component PCBA Module Plate for Bluetooth OEM PCBA
PCB Product Capability
| NO. | PCB ITEM | Manufacture capacity |
| 1 | Layer Counts | 2-22layer |
| 2 | Base Material | FR-4 / HIGH TG FR-4 / CEM-1 / CEM-3 |
| 3 | Copper foil thickness | 1oz / 1/2oz/ 1/3oz |
| 4 | PI thickness | 0.5mm-3.2mm |
| 5 | Adhesive | 13μm |
| 6 | Max. board size | 400*800 mm |
| 7 | Product thickness tolerance | ±0.05mm |
| 8 | Min. Hole Diameter | 0.2mm |
| 9 | Min.Line Width | 0.1mm |
| 10 | Min.Line Spacing | 0.1mm |
| 11 | Etching tolerance | ±0.015mm |
| 12 | PTH Hole dia. tolerance | ±0.03mm |
| 13 | NPTH Hole dia. tolerance | ±0.05mm |
| 14 | Outline Dimension tolerance | ±0.1mm |
| 15 | Outline profile | Punching / Laser cut / Drilled |
| 16 | Surface finish | HASL / OSP / ENIG / Immersion silver/Tin/Ni |
| 17 | Solder mask color | Multi-color |
| 18 | Silkscreen color | White/Black/Yellow/Green/Red/Blue and customized |
Our advantages
1. High-end, Small volume and Various kinds of PCBA service offered;
2. Speedy, Flexible and one-stop service in PCBA;
3. Assembly and Purchasing service offered, all components are promised to be purchased 100% from Original factories or their pointed agents;
4. Transparent quotation,cost and benefit are detailedly opened to customer;
5. With professional Engineers and Long-term successful experience in cooperating with customers inland and overseas, all new projects can be developed faster and better than expected;
6. With USA or Japan imported tin cream and tin bar, and 100% AOI testing during production,
All PCBAs we made are more reliable.
