High Voltage Multilayer Flex Pcb FR4 TG170 HASL Surface Finish

Large Image : High Voltage Multilayer Flex Pcb FR4 TG170 HASL Surface Finish Get Best Price

Product Details:

Place of Origin:	Shenzhen,China
Brand Name:	Betterliv/OEM
Certification:	ISO9001 FCC
Model Number:	OEM

Payment & Shipping Terms:

Payment Terms:	T/T, Western Union, Credit Card

Contact Now

Detailed Product Description

Product Name:	OEM Circuit Board Assembly	Material:	FR4 TG170
Supplier Type:	OEM	Copper Thickness:	0.3oz-12OZ
Board Thickness:	0.15mm-10mm	Min. Hole Size:	0.2mm
Min. Line Width:	0.1mm	Pcb Size:	Customized
High Light:	High Voltage Multilayer Flex Pcb , HASL Multilayer Flex Pcb , TG170 multi layer flex pcb

6 Layer F4-Flexible Multilayer PCB Fabrication High Voltage PCB Design 6 Layer PCB PCBA

FR-4 Process capability

NO	Item	Craft Ability
1	Surface Finish	HASL,Immersion Gold,Gold Plating,OSP,Immersion Tin,etc
2	Layer	1-32 layers
3	Min.Line Width	4mil
4	Min.Line Space	4mil
5	Min.Space between Pad to Pad	3mil
6	Min.Hole Diameter	0.20mm
7	Min.Bonding Pad Diameter	0.20mm
8	Max.Proportion of Drilling Hole and Board Thickness	1:10

Our service
Betterliv is a PCB supplier that offers quick online quote service.
We can provide customized solutions for LED lighting PCB and UPS PCB.
Our Rigid PCB/ FPC/LED PCB/PCBA is exported to all parts of the world.
Betterliv continuously improves the quality and service.

Advantages
• Strict product liability, taking IPC-A-160 standard
• Engineering pretreatment before production
• Production process control (5Ms)
• 100% E-test, 100% visual inspection, including IQC, IPQC, FQC, OQC
• 100% AOI inspection, including X-ray, and ICT
• High-voltage test, impedance control test
• Micro section, soldering capacity, thermal stress test, shocking test
• In-house PCB production
• No minimum order quantity
• Quick and on-time delivery
