2.93 Inch Mono Character OLED Display with 20*2 resolution
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Product Size: | 2.93 Inch | Number Of Pixels: | 20 X 2 Character |
|---|---|---|---|
| Pins: | 33 Pin | Color: | White |
| Panel Size: | 73.52x11.52x2.027mm | Active Area: | 73.52x11.52mm |
| Interface: | Parallel, 4 Wire SPI, I²C | Pixel Size: | 0.62 X 0.67 |
| Drive IC: | SSD1311 | Module Consruction: | Character Type |
| High Light: | 2.93 Inch 20*2 Character OLED Display,20*2 Mono Character OLED Display,2.93 Inch Mono Character OLED Display |
||
2.93 inch Mono Character OLED display module with 20*2 resolution and parallel Serial Peripheral IIC Interface
Product Description
HCD2W93W33S01 is a 20 Character x 2 Line COG character type OLED display module. The size of the screen is 2.93” diagonal with module dimension 73.52 x 11.52 mm. This OLED module has built-in IC SSD1311, and boasts high contrast ratio 10,000 : 1. The OLED module supports many interfaces, including6800, 8080, SPI and I2C interface.
| ITEM | DIMENSION | UNIT |
| Type | OLED Character Display | |
| Structure | Character | |
| Size (Diagonal) | 2.93 inch | inch |
| Characters × Lines | 20 Characters × 2 Lines | |
| Active Area | 73.52 × 11.52 | mm |
| Dot / Pixel Size | 0.62 × 0.67 | mm |
| Dot / Pixel Pitch | 0.65 × 0.70 | mm |
| Character Size | 3.22 × 5.57 | mm |
| Character Pitch | 3.70 × 5.95 | mm |
| Emitting Color | OLED, White | |
| IC | SSD1311 | |
| Interface | Parallel or SPI or I2C | |
| Power Supply | 2.4V-3.6V |
Application
OLED screen has a wide range of applications, it is mainly used in color display, mobile phones, BP machine, video phone, digital camera, light, green light, industrial lighting, signals, transport, finance, business, road signs, indoor and outdoor display of various information , electronic diary, electronic newspapers, office automation (OA) equipment, PDA, watch backlight, home appliances, digital cameras, high-end audio systems, portable information devices such as consumer products, car displays, airborne displays, ship-based displays.
Welcome to wholesale the customized high quality monochrome OLED display module made in China from our factory. We are known as one of the leading China manufacturers and suppliers in OLED industry and we are equipped with a professional factory.
Welcome to contact us.
